Color 1: Hunter Green / Moss Green / Foxy Gold

Color 2: Vortex Grey / Black / Charcoal Grey

FRAME

Zendit Stealth Air full Carbon, Updated Zero Suspension System, 165mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers

SIZES

S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm

REAR SHOCK

Fox Float X Factory Kashima Evol LV 205x65mm. 2-positions lever compression (Open/Firm), low-speed compression, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings

SHOCK SETTINGS

CS 30 compression, 1,1 Bleed, RL50 rebound, Rezi B40, LML, standard MCU, 0 volume spacers

FORK

Fox Podium 29 Float GRIP X2 Factory Kashima, 170mm, tapered steerer tube, Boost 20x110mm thru axle, 44mm offset. High and low-speed compression, high and low-speed rebound, air preload

FORK REMOTE

--

HEADSET

Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs, without blocklock

STEM

Onoff S9 30mm 0°, Full CNC, 31.8mm barbore

HANDLEBAR

Onoff S9 1.0 Carbon, rise: 25mm, width: 800mm, 8° backsweep, 5° upsweep, 31.8mm barbore. L and XL size: 38mm rise

GRIPS

Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size

SEATPOST

Fox Transfer Factory Kashima internal, adjustable travel, diameter 31.6mm, S: 95-120mm, M: 125-150mm, ML/L: 155-180mm, XL: 185-210mm

SADDLE

Ergon SM10 E-Mountain Black

FRONT BRAKE

Sram Maven Silver, 18mm 4-piston caliper, HS2 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

REAR BRAKE

Sram Maven Silver, 18mm 4-piston caliper, HS2 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

BRAKE LEVER

Sram Maven Silver, SwingLink and lever pivot bushings, tools-free reach adjust

RIMS

DT Swiss Hybrid HX 1700 Spline, 30mm internal width, welded aluminum, tubeless ready, 28 spokes

SPOKES

DT Swiss Straightpull spokes, DT Hybrid III, black

FRONT HUB

DT Swiss 350, Boost 20x110mm, IS 6 bolts

REAR HUB

DT Swiss 350 Classic with 24T Ratchet System, Boost 12x148mm, IS 6 bolts, XD freehub

FRONT TIRE

Maxxis Assegai 29x2.5WT, tubeless ready, 3C Maxx Grip compound, EXO+ protection, 60TPI, folding bead

REAR TIRE

Maxxis Minion DHR II 27.5x2.5 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 120x2TPI, folding bead

CRANKSET

e*thirteen Helix Race e*spec alloy. All sizes: 155mm

RINGS

Sram Eagle 36T T-Type, 104BCD, steel, CL55

BOTTOM BRACKET

--

PEDALS

--

CHAIN

Sram GX Eagle T-Type, 12s Flattop, w/Powerlock

FRONT DERAILLEUR

--

REAR DERAILLEUR

Sram X0 Eagle AXS T-Type, 12s

SHIFT LEVERS

Sram Eagle AXS Pod Controller Rocker Paddle w/discrete clamp, 12s

CASSETTE

Sram XS 1275, 10-52T, T-Type, 12s

MOTOR

Avinox M2S

BATTERY

Avinox 800Wh Battery / Avinox 4A Charger

DISPLAY

Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R)

DERAILLEUR HANGER

--

OTHERS

Sram AXS Extension Cord

WEIGHT

22.9 Kg
